Acceptance criteria of revolving door

Jul, 14, 2016

Revolving door is a gate of the doors, which usually made of glass. There are mostly swing doors such as four-wing, three wings and the like. Revolving door aesthetic, can play a role in decorating which can help enhance the corporate image.


revolving door


1. Ensure that project

Metal revolving doors, wooden revolving doors and accessories plus glass quality should meet the design requirements and related standards.

The install position and rotation flexibility of revolving door should meet the design and use requirements.

Revolving door must has a reasonable construction and reliable structure. Its installation firm, the number of embedded parts, buried, meets all of the requirements for the design and product mix.

Axis of rotation of the door must be a vertical center line of the same.

Inspection method: observation, hanging, check the amount of foot

revolving door

2. The basic project

1) the surface quality of revolving door should meet the following requirements:

Qualified: surface clean, uniform color, no pollution, no damage scratches. No significant warpage. Sew up and down evenly.

Fine: clean surface, uniform color, no pollution, no damage scratches. No warping. The vertical seam uniform, beautiful, the wood grain of wooden doors is unanimously.


revolving door


2) the installation of revolving door should meet the following requirements:

Qualified: integrity, and no loose; turn the fan split a substantially uniform plane angle, rotating light, turn the fan away from the edge of the arc gap is even, turn the fan can be stopping at any angle; no noise when turning.

Excellent: good integrity, no loose; turn the fan plane angle equally uniform. Rotating light and flexible; consistent turn the fan away from the arc edge gap, turn the fan can be stopping at any angle, no noise when turning.


revolving door


3) the closure strip (brush) installation should meet the following requirements:

Qualified: Install the correct position, strong, good sealing, exposed uniform width.

Excellent: Install the correct position, solid, sealing, and consistent exposure.

Inspection method: observation, measuring tape (angle feet) inspection.

revolving door
